The WashTrue Washing Fastness Tester is mainly used to test the color fastness to washing or dry cleaning, i.e., the ability of textiles not to fade or change color after washing or dry cleaning.
The WashTrue Washing Color Fastness Tester adopts a smart temperature control algorithm to ensure that the washing color fastness test meets the test standards and the results are reliable. This Washing Fastness Tester applies to standards such as ISO 105 C06:2010, AATCC61-2013e3, GB/T 12490-2014, M&S C4A, AATCC190-2010e2 (2016) e2, NEXT TM 02, etc. To speed up the sample preparation for washing fastness testing, you also need a SmartDispen Detergent Dispenser (figure 3).
A series of testing operations can be completed on the touch screen, such as selecting standards, parameters, time, and temperature settings, adding water, draining water, etc., it is smart and efficient, and the buzzer alarms automatically when the color fastness to washing test is completed. The WashTrue also has multiple safety designs and can run long time with low noise.
Description
Features of WashTrue Washing Fastness Tester
Smart, Easy to use, and Efficient
The smart screen interface allows direct access to various operations: selection of test standards, customization of test parameters, temperature calibration, selection of temperature increase rate, setting of time, heating temperature, etc. So, it is very convenient to do color fastness tests on fabric.
Precise temperature control, more reliable washing fastness testing
Smart temperature control algorithm achieves accurate and effective test water temperature control.
Humanized design, durable
Multiple safety protection design, the test rotating frame is equipped with an anti-jamming function to protect the equipment.
The heating is achieved by solid-state relay-controlled electric, bringing a more stable temperature and longer service life.
The water tank is made of SUS316 material, also durable. In a word, the WashTrue Washing Color Fastness Tester is reliable.
Application of WashTrue Washing Fastness Tester
Washing Color Fastness Testing is a necessary part of textile color fastness testing. So a washing fastness tester is indispensable. We can evaluate the washing color fastness of the textile quickly by using the WashTrue Washing Fastness Tester.
The WashTrue Washing Color Fastness Tester complies with a wide range of color fastness standards. Besides, the operator can choose between AATCC, ISO, and other test methods. The screen will display the corresponding parameters.
The Test Principle of Colour Fastness to Washing
Textile specimens sewn together with one or two pieces of standard lining fabric are placed in a stainless steel cup mixed with steel balls, soap or soap, and an anhydrous sodium carbonate mixture. Mechanical stirring is carried out at the specified time and temperature by the rotation of a stainless steel cup. When the colorfastness test is over, the sample will be washed and dried. Take the original sample as a reference sample, and evaluate the discoloration of the specimen and the staining of the lining fabric with gray sample cards or instruments. So we can also make a perspiration test in textiles.
Specifications of WashTrue Colour Fastness to Washing Tester
| Temperature setting range | Normal temperature (>0°C)~ 95°C |
| Heating Rate | 1.5±0.5℃/min |
| Temperature Accuracy | ± 2°C |
| Rotation speed | 40 ± 2 r/min |
| Distance from the bottom of the cup to the rotary axis | 45 ±10 mm |
Standard Accessories
Test steel cup 550±50mL or 1200±50mL 12 pcs
Stainless steel ball φ6±0.5mm 200pcs
Fuse 380V 32A 4pcs
Inlet pipe 1pc
Drain pipe 1pc
Tape 1pc
Screwdriver 1pc
Throat hoop 1pc
Sampling plate 40 x 100 mm 50 x 100 mm 50 x 150 mm 3pcs
Rubber gloves 1pc
ISO sealing or AATCC sealing 12 pcs
Measuring cup 100ml 1pc
Optional Accessories
Test steel cup 550±50mL 1pc
Test steel cup 1200±50mL 1pc
Stainless steel ball φ6±0.5mm 1pc
Stainless steel sheet φ30±2mm
thickness 3±0.5mm 1pc
ISO color change gray card 1pc
ISO color change gray card 1pc
AATCC color change gray card 1pc
DW Multi-Fiber Cloth 50m/box 1pc
AATCC No.10 Multi-Fiber Cloth 25m/roll 1pc
Standards of WashTrue Colour Fastness to Washing Tester
Standards
ISO 105 C06：2010， AATCC 61-2013e3， GB/T 12490-2014，
ISO 105-C08-2010，GB/T 29255-2012，ISO 105-C09-2010/amd.1:2003，
GB /T 23343-2009，ISO 105 C10：2006，GB /T 3921-2008，
ISO 105-E03:2010，ISO 105-E12:2010，M&S C4A，
AATCC 190-2010e2(2016)e2，NEXT TM 02
Optional Standards
ISO 105-D01：2010
GB/T 5711-2015 AATCC 132-2004e3
Power of WashTrue Colour Fastness to Washing Tester
| AC 220V 3N AC 380V 3N |
50/60 Hz 50/60 Hz |
40 A 23 A |
Weight of WashTrue Colour Fastness to Washing Tester
| 150 kg |
Dimensions of WashTrue Colour Fastness to Washing Tester
| Length: 860 mm | Width: 720 mm | Height: 1060 mm |
Welcome to TESTEX – a professional textile testing instrument supplier – WashTrue Washing Fastness Tester is on sale, contact us to get a detailed price quote.
